9173 x 1. Mk7 Jaguar Wiring Diagram Book.This comprehensive book lays out separate areas such as: Dashboard, Lighting & Signalling and Fuel Systems in comprehensive, clearly laid out, wiring chart and picture data. Sadly it does not include the actual routing on the body. Part of our comprehensive range of Exploded wiring diagram books, loved by the trade and the D.I.Y builder alike!
We are sorry, but our staff cannot offer any more technical information than that stated within the books as we are specifically XK120 / 140 & 150 specialists. If in doubt always refer to an auto-electrician.
50 YEAR OLD INFORMATION PRESENTED IN A NEW, EASY TO READ FORMAT!
9173. Wiring Diagrams Book FOR MKVII (7) Exploded Wiring
- Product Code: 9173
- Availability: In Stock
-
£11.50
+ £4.50 UK Shipping charges:
- Ex Tax: £11.50
