1 x 9192. One of our comprehensive, best selling, exploded wiring diagram books for the Jaguar E Type Series 2.

  This book covers the following areas: Dashboard, Ignition, Fuel Systems, Lighting & Signalling, Ancillaries, Engine Ancillaries, Auto Transmission, Fuse Boxes. Also includes unique drawings of front and rear of dashboard,

50 year old information presented in an easy to read format.

Please note: Sadly this book does not cover the routing of the wiring to the body.

Our part number is 9192
