One of our comprehensive best selling wiring diagram books for the Classic Jaguar XK150 Early. This book covers the iconic
Jaguar XK150 OTS, FHC and DHC, early specification models (single rear light lenses).
This book covers the following areas; Dashboard, Ignition, Fuel Systems, Lighting and Signalling modules.
Please note: Sadly the book does not contain the actual routing of the wiring to the body.
Our part number is 9188.
The XK140 design single rear lens is carried through to Early XK150 vehicles and many later U.K. spec cars.
This feature is significant in the different looms fitted between Early and Late XK150 models.
50 YEAR OLD INFORMATION PRESENTED IN A NEW, EASY TO READ FORMAT!
9188. Wiring Diagrams Book FOR Early XK150 Exploded Wiring Diagrams
- Product Code: 9188
- Availability: In Stock
-
£13.50
+ £4.50 UK Shipping charges:
- Ex Tax: £13.50
