This is a listing for a set of our wiring diagram books for all the Classic XK range, 120, 140 and 150.


This is a special listing for the shop only and is sold at a special price


They have been made here in Coventry / The UK  by us to the very highest standards, taken from original data.


As always you can rest assured that you are dealing with a 45 years established, world renown

XK120, XK140, XK150 Jaguar Specialist Company.

Please note: Sadly this book does not cover the routing of the wiring to the body.


50 YEAR OLD INFORMATION PRESENTED IN A NEW, EASY TO READ FORMAT!

9186SET. Wiring Diagram *Discounted Set of 4 * BOOKS XK120 XK140 & XK150 Exploded Wiring Diagrams (9186 to 9189)

  • Product Code: 9186SET
  • Availability: In Stock
  • £40.00

  • + £6.95 UK Shipping charges:
  • Ex Tax: £40.00
